200 Watt Portable Foldable Solar Panel
200 Watt | Portable Foldable Solar Panel | 2 Years Limited Warranty
SPECIFICATIONS
| Specification | |
| Material of Cloth | Poly 900D Waterproof Treatment on the Surface |
| Handle Color | Green |
| Kick Stands | 4 |
| Unfolding Size | 2349 x 536mm |
| Folding Size | 608 x 536mm |
| Net weight | About 8KG |
| Cable | DC Output 3m Cable with Anderson DC7909//DC5521/ DC5525 Plug |
| USB Output | 36Watt Total Output/Dual USB/18Watt Single Output 5V/3.5A, 9V/2A, 12V/1.5A |
| Specification for the Solar Panel | |
| Cell Type | SUNPOWER |
| Cell Size | 166 x 166 |
| Rated Power (Mp) | 200 Watts |
| Power Error | ±5% |
| Rated Voltage (Vmp) | 20 Volt |
| Rated Current (Imp) | 10Amps |
| Open Circuit Voltage (Voc) | 25 Volts |
| Short Circuit Current (Isc) | 11Amps |
| Operating Temperature | -40°C+85°C |
| Test Standard | Data understand and testing conditions (STC): 1000W/m², 25°C, AM1.5 |
| Manufacturer Warranty | 2 Years Against Manufacturer Defects Only |
| Temperature coefficient | |
| Nominal Operating Cell Temperature | 46°C±2°C |
| Current Temperature Coefficient | -0.05%/°C |
| Voltage Temperature Coefficient | -0.35% /°C |
| Power Temperature Coefficient | -0.45%/°C |
